Washer-Disinfectors
Endoscope washer & Disinfector: CYW-201
Features
- – Single scope cleaning and disinfection
- – Leakage test
- – Compatible with flexible scopes
- – Full automatic procedure
- – Perfect washing and disinfection by the disc rotor
- – Multi-channel jetting system rotated in 360°
- – Enhanced sensor package
(basin full sensor, drainage sensor, level(high & low) sensor for water tank, low sensor for disinfectant tank)
- – Advanced materials for anti-corrosion
- – Visible count for disinfection cycle
Specification
| Leakage Test |
Water type |
| Operating Procedure (time) |
Washing - 10~110sec, 2min~5min |
| Disinfection – 1~9min, 10~60min, 1~9hr |
| Detergent – 30 sec(Spray type) / Immersion type(max 5min) |
| Alcohol |
5sec (option) |
| Program Mode (Automatic) |
Washing - Detergent - Washing - Disinfection - Washing - Alcohol(option) - Air |
| Tank Capacity |
Water Tank: 16 Liters |
| Detergent Tank: 1.5 Liters |
| Disinfectant Tank: 20 Liters |
| Alcohol tank: 1.5Liters |
| Channel connection |
4 connection ports in a basin (1 Scope) |
| Discharge |
1 outlet (compulsory discharge on rear pannel) |
| 3 outlets (in the front door - water, disinfectant, detergent) |
| Power AC |
AC 220-230VAC, 50/60Hz |
| Dimension |
547 x 579 x 980mm(WxDxH) Open: 1320(H)mm |
| Weight |
65(80Kg option)kg |
Optional
- – Advanced water filtration system
- – UV lamp water disinfection system
- – UV light indicator
- – Thermal control system for disinfection
- – Self disinfection system
- – Alcohol purging system
- – Printer Connection
