Washer-Disinfectors
Endoscope washer & Disinfector: CYW-S601
Features
- – Using a single shot level disinfectant with accurate dilution amount control
- – Cartridge system
- – Real-time leakage monitoring function
- – Hands-Free Lid operation with easy to use foot switch to prevent cross-contamination
- – 7” wide TFT LCD touch screen with independent operating system
- – Spray arm located at top cover for dynamic washing
- – Full time leakage monitoring of endoscopes
- – Continuous channel monitoring of endoscopes
- – Barcode reading system
- – Advanced external water filtration system with standard
bacteria retention micron [0.2] water filter
- – Cycle report documentation by dynamic printing system
Specification
| Leakage Test |
Real time & Manual |
| Channel Monitoring |
6 Channel flow monitoring in all processes |
| Basin Capacity |
8Liter |
| Tank Capacity |
a. Detergent Tank: 1 Liters |
| b. Alcohol Tank: 1 Liters |
| Water filter |
Pre-filter |
| Carbon filter |
| Micron filter(0.2㎛) |
| Interface |
Barcode reading system |
| Operation |
Automatic Procedure by DB system |
| Print out all Processing steps and record in DB system |
| Couplers |
1 outlet for leakage test and 6 outlets for disinfection |
| Electrical Requirements |
220~240 VAC, 50~60Hz |
| Dimensions |
850 X 550 X 1080mm(W X D X H) |
| Weight |
80kg |
